Specifications:
(W18)
Model: W18Ā Low Power CameraHidden Spied KerĀ Hidden Spied Ker
CPU: T31Z + 2053
Viewing AngleĀ : 145Ā°
Infrared night vision: Support 6 stealth 940 infrared lamp
TF Card: Maximum support for 128G
Battery: 3400mAh (normal mode can work for about 20 hours, low-power mode can stand by for about 6 months)
Resolution: 1080P (HD),800 X 600 (SD)
Input: Built-in microphone
Wireless rate: 150Mbps(Max)
Power Adapter: DC 5V 1A
Power consumption: Low power standby mode: 1.2mAh; Normal mode: 255mAhĀ in daytime, 380mAhĀ in night vision
Infrared Illumination Distance: 5-8 meters (depending on the environment)
(W17)
Model: W17 Mini wifi CameraHidden Spied Ker
CPU: AK3918EV300
Memory: 64MB DDR2 SDRAM
Flash: 8MB
TF Card: Maximum support for 128G
Operating System: Linux
Simultaneous Access Users: 3
Input: Built-in microphone
Light Frequency: 50Hz/60Hz
Power Adapter: DC 5V 1A
Recharging Current: 450mA
Power Consumption: Full Function open up to 2.5W
Battery Capacity:1300mAh (Bulit in high capacity polymer lithium battery)
Battery Standby Time: 300 minutes
Infrared Illumination Distance: 5 meters (depending on the environment)
W17
W18
Functional featuresļ¼
1.Ā Built-in lithium battery, can not connect to the network, do not connect to the power supply of independent recording work.
2. Equipped with AP hot spot, you can connect to work locally. With WIFI wireless function, can network remote monitoring.
3. Audio and video synchronization. Photographs and videos are taken through the APP, and the device automatically records.
4. Users can choose low-power mode and normal mode.
5. The user can choose to turn on/off the motion detection alarm function. When the motion detection function is turned on, the device will actively push the alarm information to the user's mobile phone when someone intrudes into the monitoring range.
6. With PIR, in low power consumption mode, PIR triggers the recording of the device and pushes the alarm information; While ensuring that the equipment works for a long time, make sure not to miss any important information;
7. Built-in advanced dark infrared light, night vision is clear and more concealed. APP can control the infrared switch;
8. It is both a networked camera and a local monitor. It can be used as a dashcam, which is more suitable for taking evidence and recording life at any time.
9. Multiple cameras can be added to one user APP; You can also manage one camera with multiple users.
specification
model |
W18 |
Type of sensor |
1/2.9-inch CMOS sensor |
sizes |
1920*1080(2 megapixels) |
Compressed format |
H.265 |
The resolution of the |
1080P (HD),800 X 600 (SD) |
Video frame rate |
20fps |
Minimum illumination |
0lux |
Viewing Angle |
145Ā° |
Day and night functionality |
Automatic switch |
Infrared night vision |
Support 6 stealth 940 infrared lamp night vision clear, concealed |
Night vision distance |
5-8 meters |
Network protocol |
HTTP,FTP,TCP/IP,UDP,SMTP |
DHCP,PPPoE,DDNS,UPnP |
|
Wired network |
Does not support |
The wireless network |
WIFI2.4 GHzļ¼IEEE 802.11b/g/nļ¼ |
Wireless rate |
150Mbps(Max) |
A wireless connection |
WIFI Intelligent Connection |
Take the initiative to wake up |
Mobile phone remote active wake up, PIR wake up |
AP connection |
support |
stream |
Double stream |
multimedia |
support |
PIR detection |
support |
SD card video |
Support TF card storage, the maximum support 128G |
SD card timing recording |
support |
Voice compression format |
G711A |
Built-in battery |
3400mAh (normal mode can work for about 20 hours, low-power mode can stand by for about 6 months) |
The power supply specifications |
DC5V/1A |
Single weight volume (cm) |
205g Ā 3.8*4.2*5.3cm Ā |
Color box size & weight |
14.3*8.8*4.2cm |
Carton size |
48*45*31cm |
Packing quantity & weight |
105pcs Ā Ā 22kg |
Power consumption (mAh) |
Low power standby mode: 1.2mAh; Normal mode: 255mAh in daytime, 380mAh in night vision; |
Installation environment – humidity |
20% ~ 85%(non-condensation) |
Installation environment – temperature |
ā10Ā°Cļ½50Ā°C Ā |
Store humidity |
0%-90% (non-condensation) |
Mobile phone type supported |
The iphone, android, |
