E-ACE A38 Car Dvr Dash Cam Dual Len Rear View Mirror Auto Dashcam Recorder Registrator In Car Video Full Hd Dash Camera Vehicle
Features And Specifications
|
Installation Type
|
Rearview Mirror, suitable for all vehicles with mirror
|
Screen(Display) Size
|
12.0 Inch Touch IPS Screen
|
|
Chipset(Processor/CPU)
|
Huawei Hisilicon
|
|
Camera Sensor
|
Front 2MP + Rear 1MP
|
|
Camera Lens
|
Front + Rear; 6 Glass + 4 Glass; 170 Degree Angle + 140 Degree Angle; F2.0 Aperture + F2.0 Aperture
|
|
Video Resolution
|
Front: 2560*1440P@30FPS; Rear: 1920*1080P@30FPS
|
|
Photo Resolution
|
12M
|
|
Video Code
|
MJPG
|
|
Battery
|
Built-In (Built-in battery is very small, can not support working, only for save time&setting, please use original power charger when working)
|
|
OSD Languages
|
English, Russian, Chinses, Japanese, Korean,etc….. (If you want other languages,tell us,we will help you add it)
|
|
Basic Features
|
G-Sensor, Cycle Recording, Motion Detection, Parking Monitor, Time&Data Display, Wide Dynamic Range, Picture in picture display, ON/OFF Automatically
|
|
Memory Card
|
Micro SD Card, class 10 and 16GB to 64GB (Not included)
|
|
Rear Camera Upgrade
|
Support max 6 meters cable Rear Camera
|
|
Add Features
|
Night Vision, 2560*1440P front Camera With 1080P Rear Camera
|
|
More Features
|
Coming soon…..
|
|
Packing List
|
Basic:
1 x Packaging box
1 x DVR 1 x Power charger 1 x User manual |
1 x 1080P Night Vision Rearview Camera With 6/10 Meters Cable(Optional)
|
1 x Buck Line For 24H Parking Monitoring(Optional)
|
||
1 x Real Class 10 High Speed TF Card(Optional)
|
||
Adding…
|
||
Adding…
|
||
Pay Attention
|
About 24h Monitoring
|
The DVR is only compatible with cars that have a 12V power supply. A 24V power supply will burn the motherboard. If you want to use 24V, please add a 24V to 12V Converter(BL).
|
About Video |
Our Car DVR is FHD 1080P Video Recorder,must use high quality Class 10 TF Card, any low quality/low speed TF card all can't support our DVRs work normally, if you can't make sure you have good TF Card,please buy our Original TF Card together. |
2K Higher Quality Images
Real HD 1440P help to identify vital details such as license plates,driver actions and road features which may prove your innocence.
Streaming Media DVR Mirror
This is all new technology for rearview mirror dvr. A38 is equipped with this advanced streaming media technology,makes the driving rear view angle more widely,it is triple wide view angle then the traditional mirror.
It is not affected by obstacles or natural weather
Dvr use HD to provide you with flawless images in rain, fog, snow, or even at low-light level.You will be able to observe all the details with ease for outside or inside.
Huawei Hisilicon Chipset
A38 use Original Hisilicon Chip and Sony image sensor. Picture quality is more detailed.
1:1 Split Screen
1:1 split screen design to switch front and rearview recording, big screen and clearly and ersily to check rear view.You can switch views by swiping your finger left or right. It contains 3 views: front view, rear view, front & rear view.
12 Inch Touch Super Screen Display
12 inch touch screen, more convenient to operate, you can very fast operation of the car camera, so that you are safer in driving.
2.5D Curved Surface Screen
2.5D curved glass design,scratch-resistant ,anti-glare,anti-fingerprint.
Angle of Wiew Adjustable
Move the screen up or down to get more view. You can adjust the appropriate angle of view by long pressing the screen and moving your finger up and down, Gently swipe to switch views.
6 Glass HD Lens
The front camera image sensor is Sony IMX335, and 6-lens quality offers non-deforming images, together with 170° wide angle, captures the whole road’s picture in 1440P high resolution.
Front HD 2560*1440P + Rear 1920*1080P
2560*1440P Ultra HD + Rear 1920*1080P help you clearly record every moment.
Dual Camera Simultaneously Recording
170 Degree Angle front camer with 140 Degree Angle Night vision Rear view Camera (Optional) that allows for simultaneously recording videos from two different angles. Two split view make you have clear view from front and back-up camera.
Real-time Display Reverse Parking view
Smart rear view angle switch between driving and parking.You could see all further vehicles and objects clearly behind. you while real-time driving and it will switch the rear view camera automatically to give a closer backup image when parking.
About Choosing The Length Of Rear Camera Cable
There are 2 lengths of rear camera (up to about 10 meters) can be chosen,suitable for cars of different lengths.Please choose the rear camera according to the length of your car.
FULL HD 1080P Rear View Camera (Optional)
1080P resolution clear viewing rear view images, and a reversing line better than the original rearview images, reversing more secure.
Loop Recording
When this feature is turned on, the memory card is full and the oldest video will be overwritten by the newly recorded video.However, videos under special conditions will not be overwritten, such as G-sensor, Parking Monitoring.
G-Sensor
When your car is subjected to an impact or other emergency, the G sensor is triggered, so that the recorder immediately records and locks the video.
Parking Monitor
If you are worried about your car being damaged by someone else after parking, you can use our buck line to connect the DVR to ensure that the recorder works 24 hours.If someone else hurts your car and the shock triggers the G-sensor, the DVR will immediately turn on and record the situation.
Buck Line
Use the buck line to not occupy the cigarette lighter interface.
First, connect the negative pole(black line) of the buck line to the ground of the car fuse box;
Secondly, if you want to continue monitoring after parking (the DVR works 24 hours), connect the positive pole(red line) of the buck line to the BAT interface of the car fuse box;
If you want to stop monitoring after parking (the DVR does not work after parking), connect the positive pole of the buck line to the fuse box ACC interface.
Time-lapse video
Time-lapse video can be continuously recorded for 24 hours, more secure and convenient.
Easy to look back at the video.
No need to format the memory card often.
(Note: Need to buy Buck line)
WDR Dynamic Light Processing
For local exposure control frame(eliminates glare and dimming)
Video Display
Product Display
Packing List
A38
-1 x DVR(Without Rearview Camera)
-1 x Power charger
-1 x User Manual
-2 x Bandage
-1 x USB Card Reader(Gift)
A38+6M RCC
-1 x DVR
-1 x Power charger
-1 x User Manual
-2 x Bandage
-1 x USB Card Reader(Gift)
-1 x 1080P Rearview Camera With 6Meters Cable
A38+6M RCC+BL
-1 x DVR
-1 x Power charge
-1 x User Manual
-2 x Bandage
-1 x USB Card Reader(Gift)
-1 x 1080P Rearview Camera With 6Meters Cable
-1 x Buck Line For 24H Parking Monitoring
A38+10M RCC
-1 x DVR
-1 x Power charge
-1 x User Manual
-2 x Bandage
-1 x USB Card Reader(Gift)
-1 x 1080P Rearview Camera With 6Meters Cable
A38+10M RCC+BL
-1 x DVR
-1 x Power charge
-1 x User Manual
-2 x Bandage
-1 x USB Card Reader(Gift)
-1 x 1080P Rearview Camera With 10Meters Cable
-1 x Buck Line For 24H Parking Monitoring
About Rear Camera Installation
Please connect the rear camera's Red cable wire with your car reverse lamp power 's Positive pole(+). and then plug the car charger into the cigar lighter to power supply the car dvr.When you get your car in Reverse Gear,the car dvr will automatically switch to the rear camera with parking line.Then the auto reversing function will work.
